15 Ranges up to 100 lbs or 50kg
Incredibly durable and user-friendly, the economical Checkline MF mechanical force gauges are excellent for push/pull force testing in manufacturing, material testing, maintenance and inspection applications.
The peak force mode features an easy push-button reset; this is especially helpful for doing repetitive testing in an assembly line or in quality control. The large dial indicator allows viewing of force changes as they occur. This large dial reduces the chance for parallax errors when taking readings.
The Check-Line MF was ergonomically designed for handheld use, but may also be used with the optional handle-great for loads over 15 pounds (6.8 kg). Due to its mechanical design, response time is immediate. Calibration is achieved by a set of precisely matched springs which are overload protected to 165 pounds (75 kg)!
MF gauges feature a die-cast aluminum housing which mounts easily to all of our test stands for even greater control of repetitive testing. All standard Series MF gauges include a protective carrying case plus attachment adapters.
Accuracy ± 0.2%
Easy-to-read analog scale
Peak mode retains highest reading
Overload protection up to 165 pounds
100% mechanical, no batteries required
Supplied as a complete kit with several attachments in a foam fitted carrying case
2-Year Warranty
Accuracy | ±0.2% F.S. |
Display | Analog dial, 2" (50mm) diameter |
Operating Modes | Real time or Peak-Hold |
Overload Protection | 165lb (75kg) |
Standard Accessories | flat head, hook, chisel, notched head, cone head, extension rod, large hook and large V-hook all supplied in a foam fitted carrying case |
Weight | 1.6 lbs (0.73 kg), net |
Warranty | 2 Years |
订货清单
The complete kit includes the MF gauge with flat head, hook, chisel, notched head, cone head, extension rod, large hook and large V-hook all supplied in a foam fitted carrying case
配件
MFP-HANDLE Handle for MF Force Gauge
NISTCAL NIST Traceable Calibration Certificate
订货型号
Model | Capacity | Resolution |
MF-2 | 2 lbs | 0.01 |
MF-5 | 5 lbs | 0.025 |
MF-10 | 10 lbs | 0.05 |
MF-20 | 20 lbs | 0.20 |
MF-30 | 30 lbs | 0.20 |
MF-50 | 50 lbs | 0.25 |
MF-100 | 100 lbs | 0.50 |
MF-1KG | 1 kg | 0.005 |
MF-2KG | 2 kg | 0.01 |
MF-3KG | 3 kg | 0.02 |
MF-5KG | 5 kg | 0.025 |
MF-10KG | 10 kg | 0.05 |
MF-20KG | 20 kg | 0.10 |
MF-30KG | 30 kg | 0.20 |
MF-50KG | 50 kg | 0.25 |
