Accuracy of ± 0.2%
23 Ranges Available
Checkline PS Rugged construction and excellent accuracy make these force gauges ideal for tension and compression quality control measurements. Many ranges are offered, calibrated in Pounds, Kilograms, or Newtons. Check-Line PS
Ideal for push / pull measuremnts in all envirements
Real Time force display with peak capture
Free manufacturer´s calibration report
Full set of accessories and carrying case included
Zero Tare Ring to zero the gauge in each position
Hand-held use or can be mounting a on test stand
ISO/IEC 17025 Long-form Certificate & Test Data is optionally available
2 Year Warranty
Includes NIST Traceable Calibration Certificate
订货清单
The complete kit includes the gauge, five measuring tips including; flat head, cone, chisel notched, small hook, large hook,Y-hook and three inch extension rod and instruction manual -- all supplied in a fitted hard plastic carrying case.
配件
ISO-17025 Upgrade from 3 point NIST traceable cert to ISO-17025 Certificate
OH-1 Double Sided Handle For Digital Force Gauges
订货型号
Model | Capacity (resolution) |
PS-32OZ | 32 ozf (0.25 ozf) |
PS-80OZ | 80 ozf (1 ozf) |
PS-2 | 2 lb (0.01 lb) |
PS-5 | 5 lb (0.025 lb) |
PS-10 | 10 lb (0.05 lb) |
PS-20 | 20 lb (0.1 lb) |
PS-30 | 30 lb (0.2 lb) |
PS-50 | 50 lb (0.25 lb) |
PS-100 | 100 lb (0.5 lb) |
PS-0.5KG | 500 gf (2.5 gf) |
PS-1KG | 1 kg (5 g) |
PS-2KG | 2 kg (10 g) |
PS-3KG | 3 kg (20 g) |
PS-5KG | 5 kg (25 g) |
PS-10KG | 10 kg (50 g) |
PS-30KG | 30 kg (200 g) |
PS-20KG | 20 kg (100 g) |
PS-50KG | 50 kg (250 g) |
PS-10N | 10 N (0.05 N) |
PS-20N | 20 N (0.1 N) |
PS-30N | 30 N (0.2 N) |
PS-50N | 50 N (0.25 N) |
PS-100N | 100 N (0.5 N) |
PS-200N | 200 N (1 N) |
PS-300N | 300 N (2 N) |
PS-500N | 500 N (2.5 N) |
