The Checkline TT-QCM Torque Tester is designed for verification and calibration of a wide range of torque wrenches and torque tools. It's bench top design is perfect for testing click, dial, and digital wrenches, plus most power tools including impulse, DC electric and pneumatic.
A large LCD display with easy to navigate menu allows for quick setup. Storage memory allows 999 data points to be saved to the unit for review, or transmitted to a local printer or PC via the standard RS232 interface. High and low limits are easily set, and a panel mounted LED provides visual notification to the user when torque reaches these limits. Systems include dedicated internal transducers in vertical or horizontal configurations, it can be switched by the operator after purchase. Check-Line TT-QCM
±0.5% Accuracy of indicated reading from 10-100% of the capacity (Bidirectional), ±0.25% Optional
3 modes of operation: Track, Peak and 1st Peak
Eight (8) selectable engineering units: Oz.in., Lb.in., Lb.ft., Nm, cNm, KgfCm, gfCm, Kgfm
NiMH rechargeable batteries provide 8-10 hours continuous use
Includes NIST-Traceable Calibration Certificate
999 Reading Data Memory
2 Year Warranty
Calibrated Range | 10-100% Full Scale, bi-directional |
Accuracy | ±0.5% Accuracy of indicated reading from 10-100% of the capacity (Bidirectional), ±0.25% Optional |
Resolution | 4 Active Digits |
Overload Protection | 200% Full Scale bi-directional |
Operating Modes | Track, Peak, 1st Peak |
Filtering | Selectable; 125Hz, 250Hz, 500Hz, 1000Hz, 1500Hz and 2000Hz |
Data Output | RS-232 |
Memory | 999 Readings |
Alarm Limits | Panel Mounted LED for Visual Alarm Limits |
Power | Internal NiMH battery, AC Adapter / Charger (included) |
Weight | Aproximately 3lbs depending on transducer |
Operating Temp | 32 - 120 °F (0-50 °C) |
Warranty | 2 Years |
Calibration Certificate | Includes NIST Traceable calibration certificate with data |
Standard Accesories | Joint Simulator for 1/4" & 3/8" drives, AC adapter/Charger |
Optional Accessories | Joint Simulators for 1/2", 3/4" & 1" Transducers |
配件
ER Extended Range, increases certified range to 5-100% (instead of 10-100%) PER TRANSDUCER
UPG-25 Upgrade Accuracy from ±0.5% to ±0.25% - PER TRANSDUCER
TT-QCM-CC Waterproof Carrying Case for TT-QCM
TT-SOFT Data Transfer Software for TT Series, Includes USB Output Cable
订货型号
Model | Range | Drive Size | Run-Down |
TT-QCMIO-50 | 5 - 50 ozf-in | 1/4" | Included |
TT-QCMIO-100 | 10 - 100 ozf-in | 1/4" | Included |
TT-QCMIO-200 | 20 - 200 ozf-in | 1/4" | Included |
TT-QCMI-10 | 1 - 10 lbf-in | 1/4" | Included |
TT-QCMI-25 | 2.5 - 25 lbf-in | 1/4" | Included |
TT-QCMI-50 | 5 - 50 lbf-in | 1/4" | Included |
TT-QCMI-100 | 10 - 100 lbf-in | 1/4" | Included |
TT-QCMI-150 | 15 - 150 lbf-in | 1/4" | Included |
TT-QCMI-250 | 25 - 250 lbf-in | 3/8" | Included |
TT-QCMI-500 | 50 - 500 lbf-in | 3/8" | Included |
TT-QCMI-750 | 75 - 750 lbf-in | 3/8" | Included |
TT-QCMI-1000 | 100 - 1000 lbf-in | 3/8" | Included |
TT-QCMF-100 | 10 - 100 lbf-ft | 1/2" | Optional |
TT-QCMF-150 | 15 - 150 lbf-ft | 1/2" | Optional |
TT-QCMF-250 | 25 - 250 lbf-ft | 1/2" | Optional |
TT-QCMF-500 | 50 - 500 lbf-ft | 3/4" | Optional |
TT-QCMF-600 | 60 - 600 lbf-ft | 3/4" | Optional |
TT-QCMF-750 | 75 - 750 lbf-ft | 3/4" | Optional |
TT-QCMF-1000 | 100 - 1000 lbf-ft | 1" | Optional |
TT-QCMF-2000 | 200 - 2000 lbf-ft | 1" | Optional |
