Measuring Range in Steel

Pulse-Echo Mode (Pit & Flaw Detection) measures from 0.025 to 19.999 inches (0.63 to 500 millimeters).

Echo-Echo Mode (Through Paint & Coatings) measures from 0.1 to 1 inch (2.54 to 25.4 millimeters).

The new Dakota MMX-6 Wall Thickness Gauge accurately measures wall thickness and the extent of corrosion of all metals, ceramics, glass and most rigid plastics - from only one side!

The MMX-6 can be used in a Single Thickness Reading mode or in a Scan mode , where the probe is dragged over a large measuring area. The minimum thickness reading recorded during the "scan" will be displayed.

The MMX-6 probe is waterproof and can be submerged in water. The gauge is impact-resistant and environmentally sealed to provide trouble-free operation under the toughest field conditions.

DAKOTA公司在MX系列超声波测厚仪的基础上，成功地增加了一些新功能而开发了全新MMX系列多功能产品。MMX-6和MMX-6DL不仅兼容了MX系列探头的耐久性等特长，还增加了涂层穿透功能--在被测物表面有油漆时，无需去除油漆而测量材料的净厚度。

另有穿透能力更强的MMX-6 ER/MMX-6DL ER，穿透测量范围可达3.2-100mm,涂层厚度可大1.9mm。

脉冲-回波模式：0.63-500mm（探伤和探坑）

回波-回波模式：2.54-25.4mm（透过油漆和涂层侧厚度）
