Series5/M5系列是美国MARK-10公司原装进口高级型数字推拉力计，可自动识别拉压力检测,测量范围0.12 lb - 2,000 lbF (0.5 N - 10 kN)。采样频率高达7000Hz，测量精度:满量程的±0.1%，分辨率1/5000，在测量范围广的情况下保证其测量结果的可靠性。

自带背光式LCD液晶大显示屏，可显示读数，峰值保持显示和瞬时测量值显示。标配USB及RS-232，Mitutoyo(数字)输出和模拟量信号输出功能，可以自主编程使外部设备触发控制指令。

最大存储1000个测量读数，具最大值、最小值和平均值统计功能，可设上下限报警, 外部触发模式，触点开关测试或远程停止

可直接手持测量或固定在设备上使用,也可以安装在mark-10公司电动支架ESM301上,精确控制速度,行程及力的大小.配以多种夹具,方便实现各种插拔力,剥离力,拉伸力等的测量

可连接电脑.测力计配置MESUR TMLite数据传输软件,显示测量数据曲线图形，软件连续记录测量数据也可记录单个测量数据。测量数据可以一键式导入Excel.

Series 5 advanced digital force gauges are designed for tension and compression force testing in numerous applications across virtually every industry, with capacities from 0.12 lb to 2,000 lbF (0.5 N to 10 kN). The gauges feature an industry-leading sampling rate of 7,000 Hz, producing accurate results even for quick-action tests. Accuracy is ±0.1% of full scale, and resolution is 1/5000. A large, backlit graphics LCD displays large, legible characters, while the simple menu navigation allows for quick access to the gauges’ many features and configurable parameters. Data can be transferred to a PC or other data collector via USB, RS-232, Mitutoyo (Digimatic), or analog outputs.

On-board data memory for up to 1,000 readings is included, as are statistical calculations and output to a PC. Integrated set points with indicators are ideal for pass-fail testing and for triggering external devices such as an alarm, relay, or test stand. The gauges are overload protected to 200% of capacity, and an analog load bar is shown on the display for graphical representation of applied force.

The Series 5’s averaging mode addresses the need to record the average force over time, useful in applications such as peel testing, while external trigger mode makes switch activation testing simple and accurate. An ergonomic, reversible aluminum design allows for hand held use or test stand mounting for more sophisticated testing requirements.

Series 5 force gauges are directly compatible with Mark-10 test stands, grips, and software.

The gauges include MESUR™ Lite data acquisition software. MESUR™ Lite tabulates continuous or single point data. One-click export to Excel allows for further data manipulation.
